AX211 HDMI 2.1 Audio Extractor (HDMI Audio) | 4K 120Hz | eARC

Use your HDMI sound system for gaming and home theater in 8K or 4K 120Hz without compromising on picture and sound.

Designed for sound systems with HDMI input: Transmit high-resolution audio signals such as Dolby Atmos and DTS:X losslessly to your HDMI sound system for an immersive sound experience.
Support for 8K 60Hz and 4K 120Hz: Enjoy lossless video and audio transmission, ideal for modern home theater and gaming setups.
eARC support: Easily transfer TV sound to your sound system.

€89,99

Tax included Shipping calculated at checkout.

Are you still unsure if it is the right solution for you? Contact us ! We are here to help you.

Does your company need a technology upgrade?
We make sure that your company is well equipped. Write to us and let us find the ideal solution! Inquire now

Specifications

HDMI version

HDMI 2.1 up to 48 Gbit/s
Video resolution

-
Number of HDMI inputs

1
Number of HDMI outputs

1
Audio output

1x HDMI audio
Compatible with eARC sound system

-
Supported audio formats on audio out

Dolby Atmos, DTS-X, multi-channel PCM up to 7.1, Dolby Digital 2.0 / 5.1, DTS 5.1, Dolby Digital Plus, Dolby TrueHD, Dolby MAT, DTS-HD, Stereo
EDID management

Yes
Supported gaming formats

VRR, ALLM, QMS, QFT, SBTM
HDR (High Dynamic Range)

-
HDCP
- HDCP 2.3
- HDCP 2.2
- HDCP 1.4
HDMI-CEC control

Yes
HDMI-ARC from TV

Yes
Auto switching

-
Remote control

-
Power source
- Netzteil 5V DC (Euro-Stecker)

That's why we love this product

Perfect for older AV receivers:Connect modern devices such as gaming consoles or streaming boxes to your AV receiver with HDMI input and enjoy immersive formats such as Dolby Atmos without upgrading to a new sound system.
Seamless image and sound transmission:Pass HDMI signals losslessly to your display and sound system – ideal for impressive 8K streaming or 4K gaming at 120Hz.
Easy integration into the home cinema:Use ARC to send TV sound to your sound system and control everything conveniently via the TV remote thanks to HDMI-CEC support.

Scope of delivery

HDMI 2.1 audio extractor, power supply with Euro plug, instructions

AX211-manual.pdf

AX211_CE.pdf

Use your existing sound system for gaming and home cinema without limits

Use your existing AV receiver or HDMI sound system without restrictions - even in combination with the latest 4K and 8K displays. The AX211 combines old and new technologies by transmitting high-resolution sound and video losslessly, enabling an impressive home theater and gaming experience.

Support for 8K 60Hz and 4K 120Hz

The AX211 HDMI 2.1 Audio Extractor ensures lossless video and audio transmission at resolutions up to 8K 60Hz and 4K 120Hz. This high performance makes it perfect for demanding home theater and gaming setups that require sharp images and smooth playback. With the integrated gaming features such as VRR (Variable Refresh Rate) and ALLM (Auto Low Latency Mode), you will experience smooth gameplay and lightning-fast response times.

Transmit TV sound thanks to ARC support

With ARC (Audio Return Channel), you can effortlessly play your TV's internal audio through your sound system. Connect the AX211 to the HDMI-ARC or HDMI-eARC port on your display and activate eARC. The AX211 automatically detects whether the sound is coming from the TV source or an external device for a smooth audio experience.

Experience immersive sound formats such as Dolby Atmos and DTS:X

With the AX211 HDMI 2.1 Audio Extractor you can enjoy high-resolution sound formats such as Dolby Atmos and DTS:X. These advanced audio formats provide an immersive sound experience that allows you to immerse yourself deeply in the world of your film or game. Whether it's home cinema or gaming, the AX211 offers you the perfect sound for every entertainment setup.

AX211 HDMI 2.1 Audio Extractor for sound systems with HDMI input

HDMI Audio Extractor for operating display and sound system with normal HDMI input
Sound output from the player or display (if the TV has HDMI-ARC/eARC)
EDID management to control the maximum audio and video formats
Supports video formats up to 8K 60Hz or 4K 120Hz as well as gaming features such as VRR
Not suitable for a soundbar that only has HDMI-ARC or HDMI-eARC! Not for Sonos / Bose soundbars!

HDMI Audio Extractor

The AX211 HDMI 2.1 Audio Extractor is a powerful solution for seamlessly transmitting sound from an HDMI source to your HDMI sound system. It passes the audio signal through an HDMI output while simultaneously allowing lossless transmission of the video signal to your display. Whether modern TVs, older AV receivers or gaming headphones with an HDMI connection - the AX211 is ideal for all setups.

Whether you're using gaming consoles like the PS5 or Xbox, a PC, or streaming boxes like Apple TV and Fire TV, the AX211 offers the flexibility to combine older sound systems with new displays, supporting high-resolution sound formats like Dolby Atmos and DTS:X to ensure an immersive sound experience.

The AX211 optimizes audio transmission by eliminating possible latency, ensuring audio quality remains high at all times. The AX211 can also play audio formats that your TV may not support, such as DTS, so you can get the most out of your audio sources, regardless of the TV's limitations. With support for the latest HDMI standards, the AX211 guarantees outstanding audio and video quality for all your entertainment needs.

Supports resolutions up to 8K 60Hz and 4K 120Hz

The AX211 supports impressive resolutions of up to 8K at 60Hz HDR and 4K at 120Hz, with a maximum data rate of 48 Gbps. Thanks to backward compatibility to lower resolutions, the AX211 ensures lossless video and audio transmission, regardless of the source used. In addition, it offers HDMI 2.1 gaming features such as Variable Refresh Rate (VRR), which reduce image stuttering and enable smooth gameplay. Auto Low Latency Mode (ALLM) ensures that latency is automatically minimized, further improving response time in games. This means you can enjoy the best picture and sound quality both when gaming and streaming.

ARC support

Thanks to ARC (Audio Return Channel) support, the AX211 enables seamless audio transmission from the TV to the connected sound system. Simply connect the AX211 to the HDMI-ARC or HDMI-eARC port on your display and activate the eARC function. The AX211 automatically detects whether the sound is coming from the connected source or the TV, ensuring effortless switching. This function improves your home theater experience by creating an easy connection between your TV and the sound system while ensuring high-quality audio output. Whether you're streaming movies or playing games, you'll always get the best sound. In addition, it's possible to connect a monitor or video projector without ARC function and deactivate eARC, giving you flexibility in choosing your devices.

Flexible EDID management: Customize audio and video formats

The AX211 features flexible EDID management that allows you to customize the maximum supported audio and video formats. The integrated dip switch lets you choose between different EDID modes to ensure that your audio and video output is optimally tailored to your connected devices. This improves compatibility with different displays and sound systems and prevents potential conflicts in signal output. With this feature, you can ensure that both image and sound quality remain at the highest level, regardless of the source or connected device.

Selectable EDID modes:

Dip	Video	Audio
111	COPY*	COPY*
001	COPY*	Audio 5.1 DTS/Dolby/PCM 2.0
000	COPY*	Audio 7.1 DTS/Dolby/HD/PCM7.1 (recommended)
110	4K 60Hz 4:4:4	Audio PCM 2.0
101	FRL12G 8K HDR	Audio PCM 2.0
100	FRL12G 8K HDR	Audio 5.1 DTS/Dolby/PCM 2.0
011	FRL12G 8K HDR	Audio 7.1 DTS/Dolby/HD/PCM7.1
010	FRL12G 8K Dolby Vision	Audio 7.1 DTS/Dolby/HD/PCM7.1

*COPY means that the EDID data of the connected display 1 will be adopted.

FRL12G enables a maximum data rate of 48 Gbps (HDMI 2.1 Maximum)

Volume control via the TV remote control with HDMI-CEC

With a TV that has an HDMI ARC or eARC connection, you can control the volume of your audio signal directly from the TV remote control. This feature makes operation easier as you do not need a separate remote control for your soundbar. In addition, many streaming devices, such as Apple TV or Fire TV, also offer the option of controlling the audio system independently, which gives you additional flexibility in operation.

switching on and off

By long pressing the eARC button you can turn the extractor on or off.

Technical data:

HDMI version 2.1
Supported copy protection HDCP 2.3 or older
Signal input: HDMI, HDMI-eARC/ARC
Signal output: HDMI, HDMI audio only
data transfer rate max. 48 Gbps
Supported video formats up to 8K 60Hz YUV420 12-bit or 4K 120Hz RGB/YUV444 12-bit
Supported HDMI 2.1 functions VRR, ALLM, QMS, QFT, SBTM
HDR (High Dynamic Range): HDR10, HDR10+, Dolby Vision, HLG
HDMI-CEC pass-through: yes, input <> output
Supported audio formats (Extractor): LPCM 2.0-7.1, Dolby Digital, Dolby Digital Plus (incl. Atmos), Dolby TrueHD (incl. Atmos), Dolby MAT, DTS, DTS-HD (incl. DTS-X)
Supported audio formats (pass-through only): LPCM 2.0-7.1, Dolby Digital, Dolby Digital Plus (incl. Atmos), Dolby TrueHD (incl. Atmos), Dolby MAT, DTS, DTS-HD (incl. DTS-X), DSD
Recommended HDMI cable length: in <2 m, out <2 m (8K/4K120Hz) or in < 6 m, out < 6 m (4K 60Hz)
power consumption < 4.5 W
Dimensions (WxLxH) 95 x 68 x 18 mm

Product Comparison

Browse this category

Compare our HDMI Audio Extractor for sound systems with HDMI input

A table comparing the facets of 5 products
Facet	SW411 HDMI 2.1 Switch 4 In 1 Out with HDMI Audio Extractor (HDMI Audio, Toslink, AUX) \| 4K 120Hz \| eARC View details	AX211 HDMI 2.1 Audio Extractor (HDMI Audio) \| 4K 120Hz \| eARC View details	VSW04202 HDMI Switch 4 In 1 Out \| 4K 60Hz \| HDMI HD Audio Extractor \| Auto switching View details	VAX01202 HDMI eARC Audio Extractor & Splitter View details	AX110 HDMI eARC Audio Converter \| Convert TV sound for HDMI sound systems View details
Price
Price	Regular price €139,00	Regular price €89,99	Regular price €89,99	Regular price €59,99	Regular price €69,99
Rating
Rating	(18)	(11)	(21)	(20)	(9)
HDMI Version
HDMI Version	HDMI 2.1 up to 48 Gbit/s	HDMI 2.1 up to 48 Gbit/s	HDMI 2.0b up to 18 Gbit/s	HDMI 2.0b up to 18 Gbit/s	HDMI 2.1
HDMI Inputs
HDMI Inputs	-	-	-	-	-
HDMI Outputs
HDMI Outputs	1	1	1	1	0
Audio Output
Audio Output	1x HDMI audio 1x Toslink 1x AUX	1x HDMI audio	1x HDMI audio 1x Toslink 1x AUX	1x HDMI audio	1x HDMI audio
Video Resolution
Video Resolution	-	-	-	-	-
HDMI-CEC Control
HDMI-CEC Control	Yes (via HDMI)	Yes	No	Yes	Yes
EDID-Management
EDID-Management	Yes (audio only)	Yes	Yes (audio only)	No	No
Auto-switching
Auto-switching	Yes	-	Yes	-	-
Supported gaming formats
Supported gaming formats	-	-	-	-	-
HDMI ARC from TV
HDMI ARC from TV	Yes	Yes	Yes	Yes	Yes
Compatible HDCP
Compatible HDCP	HDCP 2.3 HDCP 2.2 HDCP 1.4	HDCP 2.3 HDCP 2.2 HDCP 1.4	HDCP 2.2 HDCP 1.4	HDCP 2.2 HDCP 1.4	-

Well thought out and high quality device that can save you a lot of money on a new AVR.

After purchasing my new LG C4, I was faced with the problem that although the LG can utilize the full gaming features (4K@120Hz) of the XBOX Series X and PS5 with HDMI 2.1 and can also pass on uncompressed Dolby Atmos from the XBOX via eARC, my Onkyo TX-NR696 cannot record this uncompressed audio signal via ARC (only the compressed DD+ signal).

With the AX211, I can now avoid this problem without having to spend a four-figure sum on a new AVR.

The XBOX, the PS5 and an Apple TV 4K are now connected to the LG TV (the XBox via the AX211 as described in the product description), and a Switch and Blu Ray player are also connected to the Onkyo.

With eARC mode enabled, the AX211 reliably detects where the sound is coming from and forwards it. The Onkyo, in turn, forwards the picture and outputs the audio from the devices connected to it.

But this only works reliably if I switch off ARC on the Onkyo and connect the HDMI output to the LG TV not to the MAIN (ARC) on the Onkyo but rather to the SUB/ZONE 2 or alternatively simply do without CEC altogether.

Previously, my AVR was always stuck in a continuous loop and constantly switched sources when I had several active.
But now CEC is working perfectly for me again.

Thanks to FeinTech for this ingenious solution to get the full potential out of a setup that you want to upgrade with a new TV from time to time.

Very helpful product

After briefly using the AX110 (see AX110 review -> very good product), I decided to try the AX211 and was finally able to solve my problem with the eARC function. The 12-meter distance between the LG C4 and Denon X4800H didn't allow eARC. With the AX211, it works very well. My devices are wired as follows:
1.) LG C4 HDMI IN 2 (eARC) -> AX211 HDMI OUT TV (eARC)
2.) Denon X4800H HDMI OUT (eARC) -> AX211 HDMI IN Source
3.) AX211 HDMI AUDIO OUT Amp -> Denon X4800H HDMI IN 4.
Important: Switch off HDMI CEC on the receiver, otherwise the sound will not be heard immediately (only after deactivating or reactivating the eARC function on the TV).

Very good HDMI 2.1 HD audio extractor

The HDMI 2.1 HD Audio Extractor AX211 from FeinTech is a "super device" and ideal for use with, for example, the latest generation Apple TV 4K with HDR10+ settings.
In conjunction with a THX-certified OLED panel from Panasonic via the HDMI TV output of the AX211 and my HDMI AV amplifier DSP-Z7 from Yamaha via the HDMI audio output, there are no complaints.
While other devices of this type experienced audio dropouts when using the HDR10+ setting, the AX211 works very stably and reliably. Simply fantastic!

It actually works!

So you're stuck with a 4K / 120Hz / G-Sync / VRR / HDR capable TV but your older high-end hifi AV receiver doesn't support these things? If you ask HiFi stores, they'll try to sell you a new AV receiver.

Well no more. You can just buy this thing, and it works! I finally can enjoy my 5.1 / 7.1 audio on my PC (connected to TV) AND have 4k 120Hz HDR & G-Sync enabled. I'm beyond excited. This device works flawlessly and it works instantly.

Be sure to set the 3 switches on the front correctly to match your setup! If you want 5.1 audio on PC from video games, you need to put it on 000!

Thank you FeinTech for saving me a lot of money buying a new AV receiver.

Works as expected.

I purchased the audio extractor to continue using my old, non-HDMI 2.1-capable AV amplifier while still enjoying 4K 120 Hz and other benefits of HDMI 2.1. The extractor performs these tasks to my satisfaction.
I encountered two minor issues. First, my old 3m HDMI cable only produced a black image at 4K 120Hz, but it worked when connected directly from the PC to the TV. I ordered a 3m cable from FeinTech that solved the problem.
Secondly, my amplifier no longer goes into standby mode with the other devices, so now when I watch a film to fall asleep, I set the timer in the amplifier.
Nothing earth-shattering, can only recommend the audio extractor.

Dieser HDMI 2.1-Audioextraktor liefert 4K 120 Hz und Dolby Atmos und verlängert so die Lebensdauer älterer AV-Receiver. Die Kunden lobten die solide Konstruktion, die einfache Bedienung und den geringen Stromverbrauch. Es „funktioniert einwandfrei“ mit Spielekonsolen und PCs. Zu den kleineren Problemen gehören gelegentliche eARC-Standby-Störungen und CEC-Konflikte, die in der Regel durch Firmware-Updates oder Einstellungsanpassungen behoben werden.

DevicePcWorksArcAx211FeintechLotMoneyProductThing

5 stars: 11 (100%)
4 stars: 0 (0%)
3 stars: 0 (0%)
2 stars: 0 (0%)
1 star: 0 (0%)

Works well!

Finally a system what works

Great product

Its a great product, and it works like it should. I first had some problems with hdr to sdr switching on my google tv streamer, however, that was gone after a firmware update, to which they had kindly send me a link. now it just works. I got dolby digital 5.1 to my denon avr 1312, and 4k hdr to my monitor.

A Helpful Device to Make an AV Receiver Last Longer

Works as described with the bandwidth to deliver 4K 120Hz and Dolby Atmos. After trying a cheaper splitter from another company which was limited to HDMI 2.0, I can say that from a PC with AMD 7800XT to my older Onkyo TX-NR636 (Atmos) & Samsung 4K 120Hz TV, this splitter succeeds in the HDMI 2.1 capabilities that I was after.

PC games work with low latency 5.1 surround sound via the appropriate EDID settings and 4K HDR films and TV are output well via the alternative EDID for Atmos, in addition to the eARC output from the TV to the ARC-capable Onkyo receiver. Atmos output from games may work too, but the true Atmos output titles on PC are limited and untested for me. CEC works too The only gripe is that after turning the TV and receiver back on, the eARC output from the TV to the receiver gets stuck in PCM mode and not Dolby Digital output - something that is amended by unplugging all plugs to the splitter, then plugging all back in. I rack this up to the strange workings of eARC and ARC, rather than a shortcoming of the AX211, and am still happy with the splitter overall. Perhaps a future firmware update would help here.

I recommend the AX211 to increase the life of an older but still very capable AV receiver to match more modern TVs and entertainment sources while reducing negative impact/waste to the environment.

Perfekt

Ich nutze es mit einem Denon AVR 3313 und Samsung U55 (ca. 2017). Funktioniert perfekt mit Linux und Nintendo Switch 2.

Solide Konstruktion, extrem einfache Bedienung, kaum Stromverbrauch.

Kontakt mit dem Support (Fehlkauf meinerseits) war schnell und direkt. Große Empfehlung!

Bisher top

aktuell läuft es und tut genau das, was es soll.

Für meine Zwecke Super Produkt

Sehr gute Kommunikation und Beratung, schnelle Abwicklung.
Sehr gerne wieder.

Durchdachtes und hochwertiges Gerät was einem eine Menge Geld für einen neuen AVR sparen kann.

Ich stand nach dem Kauf meines neuen LG C4‘s vor dem Problem, dass der LG zwar mit HDMI 2.1 die vollen Gaming Features (4K@120Hz) der XBOX Series X und PS5 ausreizen kann und über eARC auch unkomprimiertes Dolby Atmos von der XBOX weiterleiten kann, aber mein Onkyo TX-NR696 dieses unkomprimierte Audiosignal über ARC nicht aufnehmen kann (nur das komprimierte DD+ Signal).

Mit dem AX211 kann ich dieses Problem nun umgehen ohne mir für einen vierstelligen Betrag einen neuen AVR zu besorgen.

An dem LG TV sind jetzt die XBOX, die PS5 und ein Apple TV 4K angeschlossen (die XBox über den AX211 wie in der Produktbeschreibung beschrieben), am Onkyo sind noch eine Switch und Blu Ray Player angeschlossen.

Der AX211 erkennt bei eingeschaltetem eARC-Modus zuverlässig wo der Ton herkommt und leitet ihn weiter. Der Onkyo wiederum leitet das Bild weiter und gibt das Audio der an ihn angeschlossenen Geräte aus.

Das aber auch nur zuverlässig wenn ich ARC am Onkyo ausschalte und den HDMI Ausgang zum LG TV nicht am MAIN (ARC) vom Onkyo anschließe sondern lieber am SUB/ZONE 2 oder alternativ einfach komplett auf CEC verzichte.

Vorher war der AVR bei mir immer wieder in einer Dauerschleife gefangen und hat die Quellen permanent umgeschaltet wenn ich mehrere aktiv hatte.
Aber so funktioniert jetzt auch CEC wieder einwandfrei bei mir.

Danke an FeinTech für diese ausgeklügelte Lösung um das volle Potential aus einem Set Up rauszuholen was man zwischendurch mal mit einem neuen TV upgraden will.

Sehr hilfreiches Produkt

Nach kurzem Einsatz des AX110 (siehe Bewertung AX110 -> sehr gutes Produkt) habe ich mich für den AX211 entschieden und konnte endlich mein Problem mit der eARC Funktion lösen. Die Strecke von 12 Metern zwischen dem LG C4 und Denon X4800H hat kein eARC zugelassen. Mit dem AX211 funktioniert das sehr gut. Verkabelung meiner Geräte wie folgt:
1.) LG C4 HDMI IN 2 (eARC) -> AX211 HDMI OUT TV (eARC)
2.) Denon X4800H HDMI OUT (eARC) -> AX211 HDMI IN Source
3.) AX211 HDMI AUDIO OUT Amp -> Denon X4800H HDMI IN 4.
Wichtig: HDMI CEC beim Receiver abschalten, ansonsten ist der Ton nicht sofort zu hören (erst nach dem Deaktivieren bzw. Reaktivieren der eARC Funktion am TV).

Sehr guter HDMI 2.1 HD Audio-Extractor

Der HDMI 2.1 HD Audio Extractor AX211 von FeinTech ist ein „Super Gerät“ und für die Nutzung z. B. von Apple TV 4K der letzten Generation bei Einstellung HDR10+ spitzenmäßig.
In Verbindung mit einem THX zertifizierten OLED-Panel von Panasonic über den HDMI TV-Ausgang des AX211 und meinem HDMI AV Amplifier DSP-Z7 von Yamaha über den HDMI-Audio-Ausgang gibt es keine Beanstandungen.
Während es bei anderen Geräten dieser Art zu Tonaussetzern bei der Einstellung HDR10+ kam, arbeitet der AX211 sehr stabil und zuverlässig. Einfach Klasse!!

It actually works!

So you're stuck with an 4K / 120Hz / G-Sync / VRR / HDR capable TV but your older high-end hifi AV receiver doesn't support these things? If you ask HiFi stores, they'll try to sell you a new AV receiver.

Be sure to set the 3 switches on the front correctly to match your setup! If you want 5.1 audio on PC from video games, you need to put it on 000!

Thank you FeinTech for saving me a lot of money buying a new AV receiver.

Funktioniert wie erwartet.

Gekauft habe ich den Audio Extractor um meinen alten, nicht hdmi 2.1 fähigen, AV Verstärker weiterzubenutzen und gleichzeitig nicht auf 4K 120 hz und andere Vorzüge von hdmi 2.1 zu verzichten. Der Extractor erfüllt diese Aufgaben zu meiner Zufriedenheit.
Auf zwei kleine Probleme bin ich gestoßen. Zum einen lieferte mein altes 3m hdmi Kabel bei 4K 120hz nur ein schwarzes Bild, funktionierte allerdings bei direkter Verbindung von PC zum TV. Gelöst durch ein mitbestelltes 3m Kabel von FeinTech.
Zum anderen geht mein Verstärker nicht mehr zusammen mit den anderen Geräten auf standby, so daß ich jetzt, wenn ich zum einschlafen einen Film schaue, den Timer im Verstärkers einstelle.
Nichts weltbewegendes, kann den Audio Extractor nur weiterempfehlen.

Hi 👋🏻😁
If I use it with an PC or an Xbox and enable Dolby Atmos, but my AVR does not support Atmos/MAT, will the AX-211 convert MAT to multichannel PCM automatically?
Or does the AVR still receive MAT and stay silent?
Thanks!

FeinTech

No typical audio extractor converts audio formats. And you can't play Atmos if your AVR doesn't has an Atmos Decoder and Renderer. You could force the player to output Atmos if you use AX211. But the AVR stays mute then. So I am afraid there's no possibility to retrofit Atmos.

Hi, my TV is a Samsung Q77T from 2019/2020, the first ones with eARC compatible with ATMOS. I’ve noticed that detecting Atmos can be a bit hit-or-miss. Sometimes my AVR switches to Dolby Digital only, instead of Dolby Digital Plus (which enables Atmos), and it seems like the TV isn’t recognizing it properly. Is there some solution?

FeinTech

If you are using an external player, you could use the AX211 to send content with Atmos to the sound system. Then the television only has to display video and does not need to forward any audio.

Hello, my setup consists of a Samsung Q930D soundbar alongside a Samsung TV, Apple TV and a PS5. I also use the PS5 as a blu-ray and 4K player. The soundbar can decode both Dolby and DTS bitstreams when the PS5 is connected to its passthrough but I lose 120Hz output, the TV can only pass Dolby bitstreams through eArc when the PS5 is directly connected. The LPCM transcode that is passed through when watching DTS-HD MA movies directly plugged into the TV is for some reason more quiet and thin sounding than the DTS bitstream decoded by the soundbar when connected directly to it. Can I use the AX211 to pass Dolby or DTS bitstream directly from the ps5 to the soundbar, while also having eArc from the TV/Apple TV on the same cable? Also, what would be the correct EDID setting, 111? Thank you.

FeinTech

Yes, you can use the AX211 here and bypass the soundbar's limitations. You can use 120Hz and VRR for gaming if your TV supports it. Also, you can play DTS-HD from PS5 bluray. The sound of TV's apps and of a directly connected Apple TV can also be played via the soundbar. Recommended EDID setting is "000".

3 questions:

If I want to use this device like the Sharc V2 or the VAX01202 (ie as an eArc extractor only), where the source device (like a game console) is connected to the TV, and the AX211 sits between the TV’s eArc and the AVR/Soundbar, and you can use it with AVR’s that do not support eArc?

Second question:
When used as an HDMI Splitter (Xbox connected to AX211, with an output to the AVR/Soundbar and another output to the TV). Can it pass DTS:X from my Xbox to my AVR even if the TV doesn’t support DTS passthrough (like with 2019-2022 LG OLEDs)?

Third Question:
Can this pass proper Freesync handshaking when used as an HDMI Splitter from AMD GPU’s or Xbox consoles, or will it revert to generic HDMI 2.1 Forum VRR? On my LG OLEDs it will indicate in the VRR menu HDMI VRR, Gsync or Freesync, as well as the LG’s Gamebar. Will it allow for proper handshaking of the different VRR variants?

FeinTech

Yes, you can extract eARC from the TV and output it to a regular HDMI input of the AVR. It also support DTS-X audio from an Xbox when it is connected to the AX211's input. This is independent from the TV's audio format support. The AX211 supports VRR according to HDMI 2.1 specs and works fine with PlayStation PS5 and Xbox. It has not been extensively tested with proprietary formats of computer graphic cards. It is likely that it works if the graphic card has an HDMI output and not only DisplayPort. However, it can't be guaranteed.

Hello, what is the difference between ax211 and ax310? I noticed that in the description one is for soundbars and other for receivers, but other than that I could not find any technical differences. I currently have an ax211 and I was planning to use it with Sonos soundbar, is there something I will be missing out on compared to ax310?

FeinTech

The AX211 is compatible with HDMI Input ports. The AX310 is made for HDMI eARC/ARC-ports. If you want to connect the Sonos soundbar you'll need the AX310 as the Sonos soundbars come only with one HDMI eARC-port.

AX211 HDMI 2.1 Audio Extractor (HDMI Audio) | 4K 120Hz | eARC

Specifications

That's why we love this product

Scope of delivery

Downloads

What our customers are saying

Use your existing sound system for gaming and home cinema without limits

Support for 8K 60Hz and 4K 120Hz

Transmit TV sound thanks to ARC support

Experience immersive sound formats such as Dolby Atmos and DTS:X

AX211 HDMI 2.1 Audio Extractor for sound systems with HDMI input

HDMI Audio Extractor

Supports resolutions up to 8K 60Hz and 4K 120Hz

ARC support

Flexible EDID management: Customize audio and video formats

Selectable EDID modes:

Volume control via the TV remote control with HDMI-CEC

switching on and off

Technical data:

Product Comparison

Customer Reviews

Technik trifft Leidenschaft

Your cart

AX211 HDMI 2.1 Audio Extractor (HDMI Audio) | 4K 120Hz | eARC

About Us

Products

Choose options
